1. ADSL2/2+ Compliance ANSI T1.413 Issue2
| ITU-T G.992.3 ADSL2 G.dmt.bis |
| 2. ATM Protocols RFC2684 MPoA ( Multiple Protocol over AAL5) |
| RFC2516 PPPoE ( PPP over Ethernet) |
| RFC2364 PPPoA ( PPP over AAL5) |
| PPPoE pass-throuth from LAN/WLAN |
| Transparent bridge for MPoA |
| 3. VoIP Protocol : SIP,RTP/RTCP |
| G.168 Line Echo-Cancellation |
| Call Forwarding ( Always, Busy and No Answer ) |
| 4. WLAN IEEE802.11b/g compliant |
| MAC address access control |
| WDS ( Wireless Distribution System ) |
| 5. Virtual Private Network (VPN) Facilities Up to 2 VPN tunnels |
| Supported protocol : PPTP , IPSec , L2TP , L2TP over IPSec |
| Encryption : AES , MPPE and hardware-based DES / 3DES |
| Authentication : MD5 , SHA-1 |
| IKE authentication : pre-shared key and digital signature ( X.509 ) |
| LAN-to-LAN , Teleworker-to-LAN |
| Dead Peer Detection ( DPD ) |
| IPSec NAT-Traversal ( NAT-T) |
| 6. QoS ( Quality of Service ) Grarantee bandwidth for VoIP |
| Class-based bandwidth guarantee by user-defined traffic categories |
| DiffServ Code Poing classifying |
| 4-level priority for each direction ( Inbound / Outbound ) |
| Automatic WAN speed detection |
| 7. Firewall Facilities IM/P2P blocking |
| Mult-NAT, DMZ host, port-redirect / open port |
| Rule-based packet filtering |
| SPI ( Stateful Packet Inspection ) |
| 8. Network Features IGMP proxy / Snooping |
| DHCP client / relay / server |
| 9. Content Filtering URL keyword blocking ( Whitelist and Blocklist ) |
| Java applet , cookies , Active X , compressed , executable , multimedia file blocking |
| Web Content Filter ( SurfControl ) |
| 10. Router Management Web-based user interface ( HTTP/ HTTPS ) |
| CLI ( Command Line Interface, Telnet / SSH* ) |
| Administration access control |
| Configuration backup / restore |
| Build-in diagnostic function |
| Firmware upgrade via TFTP / FTP |
SNMP management MIB-II |
